ASTM B161 Pipes manufacturer & exporter


Products / Nickel Alloys / Nickel 200 / Nickel 200 Pipe

Nickel-Alloy

Nickel 200 | Nickel 200 Machinability | Nickel 200 Properties | Nickel 200 composition | Nickel 200 density | Nickel 200 datasheet | Nickel Applications

Nickel-Alloy



Nickel 200 is technically pure nickel with good mechanical properties and excellent resistance to alkali hydroxides as well as organic compositions. Even when exposed to high temperature.

Please note: we may supply special diameters in small quantities at request

Nickel 200 Pipe Manufacturer & Industrial Suppliers

Nickel Alloys Pipes
Sr. No.
Material
Size
Sch.
Specification
Manufacturer
1
Cupro Nickel
Hastelloy
Nickel
Monel
Inconel
Alloy 20
Duplex
15 NB
to
150 NB
Sch. 10
Sch. 40
Sch. 80 Etc.
IS
BS
ASTM
UNS
Imported &
Chinan Mfg.

UNS NICKEL MATERIAL GRADES
Nickel grade UNS Werkstoff DIN
NICKEL 200 UNS N02200 24,066 Ni 99.2


Source to Buy Nickel Pipe

Note:-
Nickel Alloy in Grade
  • Cupro Nickel
  • Hastelloy
  • Nickel
  • Monel
  • Inconel
  • Incolloy
  • Alloy 20, Duplex Steel, SS 904L, Etc.
  • :
    :
    :
    :
    :
    :
    :
    90/10, 70/30, 66/30/2/2
    C-4, C-22, C276, B-2
    200 / 201 / 205
    400 & K500
    600, 601, 625 & 825
    800, 800H

    In Form of Round , Etc.
    In Length of
    Standard & Cut length
    Value Added Service
    Draw & Expansion as per required Size & Length,
    Heat Treatment
    Annealed
    Machining Etc.
    Test Certificate for
    Nickel 200 Pipe
    Manufacturer Test Certificate
    Laboratory Test Certificate from Govt. Approved Lab. &
    Under Third Party Inspection
    Specialize Cupro Nickel Tube



    Nickel 200 Pipe Application
    Nickel 200 Pipe Uses
    • Architecture and construction
    • Aerospace
    • Nuclear Power
    • Fertilizers
    • Valve & Pumps
    • Petrochemical
    • Motor industry
    • Food and drink
    • Electronics
    • Transport and traffic
    • Pulp and paper industry
    • Medicine
    • Energy industry
    • Chemicals industry
    • Nickel Alloy in Pulp and Paper
    Nickel 200 Pipe Order & Packing Information
      Min. Order: 10 Pieces (or please enquire for your customized order)
    Trade Terms: FOB, CIF
    Payment Terms: L/C, T/T
    Packing: as per requirement
    Place of Origin:JIANGSU, China
    Means of Transport: Land, Ocean
    Delivery Date: one or two week



    Related Information to nickel 200 pipe

    nickel 200 tube

    Nickel 200 and Nickel 201 are solid solution strengthened, commercially pure wrought materials with good mechanical properties over a wide range of temperatures and excellent resistance to many corrosives, in particular hydroxides. Nickel 201 was a modification of 200 to control carbon (.02 max) which keeps it from being embrittled by intergranular precipitates at temperatures of 600° F to 1400° F in many processes. Typically, the elemental restrictions of both, nickel 200 and nickel 201, are combined into one, dual-certified chemistry resulting in a single alloy with the desired characteristics of both alloys, Nickel 200/201.

    Click here to know more about Nickel Tube

    nickel 200 sheet

    Both Nickel 200 and 201 offer corrosion resistance in reducing and neutral media as well as in oxidizing atmospheres provided that the oxidizing media allows the formation of a passive oxide film. This oxide film accounts for the materials excellent resistance in caustic environments. Corrosion rates in both marine and rural atmospheres are very low. The resistance of Nickel 200/201 to corrosion by distilled and natural waters is excellent.

    Nickel 200 flanges

    Good resistance to corrosion in acids and alkalis and is most useful under reducing conditions. Outstanding resistance to caustic alkalis up to and including the molten state. In acid, alkaline and neutral salt solutions the material shows good resistance, but in oxidizing salt solutions severe attack will occur. Resistant to all dry gases at room temperature and in dry chlorine and hydrogen chloride may be used in temperatures up to 550 °C. Resistance to mineral acids varies according to temperature and concentration and whether the solution is aerated or not. Corrosion resistance is better in de-aerated acid.

    Alloy 625 pipe

    We are industrial suppliers for Nickel Alloy 625 tubing and pipe,

    Product Information for Nickel Alloy 625 tubing and pipe


      Sizes   Standard Tolerances
    Products OD Wall Lengths and/or coils Grades OD Wall Lengths
    Pressure & Corrosion Tubing

    Meets or exceeds requirements for welded

    Specifications: ASTM-B704, ASME-SB704, ASTM-B705, ASME-SB705

    1/16" (1.59 mm) to 4" (101.6 mm)

    Metric sizes available

    0.010" (0.25 mm) to 0.220" (5.59 mm) Random or cut lengths up to 40' (12.9 m)

    Coils to 1-1/2" OD

    625
    <5/8" (15.9 mm) ±0.005" (0.127 mm)
    5/8" to 1-1/2" ±0.007"
    >1-1/2" (38.1 mm) to 3" (76.2 mm) ±0.010" (0.25 mm)
    >3" (76.2 mm) to 4" (101.6 mm) ±0.015" (0.38 mm)
    ±15% ±12.5% Randoms up to +2" (50.8 mm)

    Cuts +1/8" (3 mm) -0"

    Coils to 80,000' (24,384 m)

    Nickel Alloy 625 Product Range


    Alloy UNS Designation Werkstoff NR. Specifications*
    625 N06625 2.4856 B/SB704, B/SB705

    inconel 200 / Nickel 200

    Nickel 200 is commercially pure (99.6%) wrought nickel. It has good mechanical properties and excellent resistance to many corrosive environments. Other useful features of the alloy are its magnetic and magnetostrictive properties, high thermal and electrical conductivities, low gas content and low vapor pressure.

    The corrosion resistance of Nickel 200 makes it particularly useful for maintaining product purity in the handling of foods, synthetic fibers, and caustic alkalies; and also in structural applications where resistance to corrosion is a prime consideration.
    Other applications include chemical shipping drums, electrical and electronic parts, aerospace and missile components and rocket motor cases.

    Click here to know more about Nickel 200, we are also manufacturing Nickel 200 Flanges

    alloy 625 plate

    alloy 200

    is inconel 625 magnetic:

    Technically speaking Inconel 625 is a corrosion resistant, non magnetic, oxidation resistant nickel based alloy.
